New state-of-the-art facility provides access to advanced materials, manufacturing tools

A new facility at Arizona State University’s Tempe campus will give researchers and corporate partners access to a wide range of advanced materials and manufacturing tools, supporting work with cutting-edge technologies. The Biodesign Institute marked the opening with a ribbon-cutting ceremony and facility tours earlier this month.

Managed by the Biodesign Center for Sustainable Macromolecular Materials and Manufacturing, or SM3, the facility houses tools that support research such as scanning electron microscopy, thermal analysis, light scattering, mechanical testing, gas permeability measurements, water uptake analysis and rheological testing to better understand and optimize material performance.

The lab also features cutting-edge additive manufacturing technologies, ranging from extrusion-based systems to light-driven 3D printers.

Among its most notable additions is the Cubicure Caligma printer, the first system of its kind in the United States capable of integrating extrusion and light-based printing at the micron scale, opening new possibilities for precision manufacturing and materials development.

The new laboratory represents the transformation of the former ASU Biodesign Clinical Testing Lab — best known as the site of the university’s large-scale COVID-19 saliva testing operations — into a state-of-the-art research hub dedicated to advancing sustainable materials innovation.

The facility is already serving a growing community of researchers, with approximately 60 faculty members, students and staff from across ASU utilizing the space and its resources.

By bringing together expertise in materials science, engineering, chemistry and manufacturing, the center aims to accelerate the development of sustainable products and technologies while strengthening Arizona’s innovation ecosystem.

During the ceremony, attendees heard from Biodesign leaders and industry partners about the importance of investing in shared research infrastructure that can support both fundamental discovery and commercial translation.

“We’re focused on sustainability,” said Tim Long, director of the Biodesign Center for Sustainable Macromolecular Materials and Manufacturing. “And these days what does that mean? That means resiliency. It means supply chain. It means using our resources more effectively. It means being more competitive as a nation, more competitive with our companies and more effectively educating our students, the future generation, the future workforce.”

The new laboratory is also expected to serve as a catalyst for expanded partnerships with leading instrument manufacturers and private industry, helping drive Arizona-based product innovation and workforce development.

Industry representatives participating in the event highlighted the value of collaborative research environments that connect academic expertise with real-world challenges.

“What this expansion does in practice is reduce friction,” said Jeff Addy, an ASU alumnus and research and development manager from Cargill Bioindustrial. “It means you can move from an idea to real data faster, ask better questions and iterate more quickly. That changes the kind of work you can do, not just how fast you can do it.”

Following the ribbon cutting, guests toured the laboratory and explored the technologies that will support the next generation of sustainable materials research and manufacturing at ASU.

For more information: Biodesign Center for Sustainable Macromolecular Materials and Manufacturing

Image: Industry collaborators tour the Biodesign Institute’s new shared manufacturing lab managed by the Center for Sustainable Macromolecular Materials and Manufacturing on Tuesday, June 9. The facility provides access to advanced tools that support electron microscopy, thermal analysis, light scattering, mechanical testing, gas permeability, water uptake, rheology and 3D printing. Photo by Charlie Leight/ASU News

Designing matter at the nanoscale

Toni Taylor, a Los Alamos National Laboratory fellow and physicist, recalls that early terahertz research was hindered by the lack of modulators—devices that control light’s amplitude, phase or frequency—making it difficult for this promising band to reliably carry information for communications and medical applications. Situated between microwaves and infrared light, the terahertz range is too fast for conventional electronics and too slow for traditional optics, leaving it largely unmastered compared with other parts of the electromagnetic spectrum that drove advances such as radar and photonics. Because terahertz waves pass through typical modulator materials with little absorption or reflection, scientists have had limited ability to control them, creating what is known as the “terahertz gap” and leaving significant technological potential untapped.

Terahertz waves oscillate trillions of times per second, hundreds of times faster than the microwave-frequency systems used in today’s wireless networks. In principle, that behavior means they could carry vastly more information than today’s fastest consumer networks. But communications is only part of the appeal. Like x-rays, terahertz radiation can penetrate many nonmetallic materials, but unlike x-rays, it doesn’t ionize atoms, meaning it doesn’t change the materials’ structure. In theory, that makes terahertz radiation well-suited to nondestructive probing of delicate materials, from biological tissue to concealed explosives. “There just weren’t good photonics devices there,” Taylor says. “At the time, neither naturally occurring materials nor manmade alloys interacted strongly enough in that band to control it.”

By the early 2000s, when Taylor and coworkers began working in the terahertz band, the computer revolution had pushed technology to an inflection point. Moore’s Law was still busy shrinking transistors, but devices had reached dimensions small enough that quantum effects shaped performance. Advances could no longer come from simply making components smaller. To keep accelerating computation, materials had to be designed down to the level of their very atoms.

For the first time, nanoscale engineering, working at dimensions of billionths of a meter, where materials behave in fundamentally new ways, was becoming practical. Long before nano products were built, scientists could model them on supercomputers that predicted how electrons and electromagnetic waves would behave in such tiny structures. Cleanroom fabrication techniques refined by the microelectronics industry were building structures smaller than one hundred nanometers with remarkable precision, while scanning tunneling microscopes and atomic force microscopes made it possible not only to image the placements of individual atoms but, in some cases, to nudge them deliberately into place.

All of these technological factors, plus the promise of the capabilities they enabled, led the Department of Energy’s Office of Science to create the Center for Integrated Nanotechnologies, a centerpiece facility among a national network of nanoscale research centers. Opened in 2004 and jointly operated by Los Alamos and Sandia national laboratories, CINT was built as a user facility, a place where scientists from around the world could propose ideas and gain access to specialized tools and expertise. Housed within this tightly integrated environment, researchers could move from theory to synthesis to fabrication to characterization—all at the nanoscale.

For researchers like Taylor, CINT turned the terahertz gap from an abstract limitation into an engineering problem. “All of the tools needed to develop the modulators were at CINT,” Taylor says. Her team’s work on the project began in earnest in 2006, when a postdoctoral researcher named Willie Padilla arrived at Los Alamos with expertise in metamaterials: artificially structured surfaces engineered to manipulate electromagnetic waves in ways natural materials cannot.

The way a material traditionally absorbs or reflects light is dictated by its atomic composition—the electronic transitions and vibrational modes built into its chemistry.  Padilla’s insight was that they no longer had to rely on the electronic structure of naturally occurring materials to support a resonance at terahertz frequencies. They could engineer a material instead.

Using CINT’s modeling tools, he and his collaborators designed metallic patterns sized to resonate at terahertz frequencies: tiny, repeating loops and gaps etched into a thin film of gold. When a terahertz wave struck the patterned surface, its oscillating electric field drove the metal’s free electrons back and forth. If the geometry was right—if the loops and gaps were sized precisely for that frequency—the electrons would move in sync with the incoming wave. The energy in the terahertz waves that would otherwise have passed quietly through the material was briefly captured, scattered, or absorbed. Like radio antennas tuned to a single station, the gold resonators responded strongly only at the frequency dictated by their shape.

But this was still a passive response, like a filter or detector. The resonator device could isolate or suppress an individual frequency, but couldn’t change that frequency in real time. Without time-dependent control, it wasn’t yet useful for information transmission. To do that, Padilla, along with his coworkers Hou-Tong Chen, Richard Averitt, and Taylor had to find a way to modulate the signal itself.

The solution lay in setting the patterned metal resonator atop a semiconductor substrate. By injecting charge into that substrate—electrically or with an ultrafast optical pulse—the team temporarily increased its conductivity. That shift altered how freely the electrons in the resonators could oscillate. When the substrate became more conductive, the oscillations dissipated energy more quickly and the response weakened; when it was less conductive, the resonance sharpened. In practical terms, a static surface had become a controllable gate. A region of the spectrum long considered technologically awkward could now be modulated in real time. The work culminated in a 2006 paper demonstrating active control of terahertz radiation.

What followed was not just a device, but a new way of thinking about matter: that it could be modified at the nanoscale to realize ideas once confined to theory. Taylor’s group went on to pursue higher-speed modulators, tunable filters, polarization rotators, and broadband converters. They extended the same nanoscale design principles to problems across national security and optical communications. More recently, collaborators demonstrated structures that can generate and steer terahertz radiation with unprecedented control. That approach has contributed to advances in security imaging seen at airports, materials diagnostics, and next-generation wireless research. Recent experimental terahertz systems achieved data rates exceeding 100 gigabits per second, far beyond typical consumer wireless speeds.

Terahertz modulation is only one expression of CINT’s broader vision. Across the Center, researchers have applied the same integration of modeling, fabrication, and measurement to problems ranging from quantum dots to structural materials. Victor Klimov and Jennifer Hollingsworth engineered quantum dots whose optical gain and emission can be tuned with atomic precision, advancing solar technologies, microelectronics, and quantum information science. Other Los Alamos teams designed nanoscale defect architectures to strengthen materials and built atom-scale emitters matched to fiber-optic telecommunications bands. Each effort differs in application, but they share a methodology enabled by CINT: design at the nanoscale, fabricate precisely, measure rigorously, iterate quickly.

“We wanted to understand the materials and then design them to do the thing that we wanted them to do,” Taylor says. The science has advanced since the early days of terahertz modulators. The ambition remains the same: to design matter itself.

For more information: Los Alamos National Laboratory

Nikhil Bajaj’s $649K NSF CAREER Award reverses the design process for devices from microsensors to aircraft wings

Nikhil Bajaj, an assistant professor of mechanical engineering and materials science at the University of Pittsburgh’s Swanson School of Engineering, studies nonlinear systems that shift behavior once a threshold is crossed—phenomena seen across disciplines in devices that rely on bifurcation to enhance sensitivity and performance. He has received a $649,684 National Science Foundation CAREER Award to rethink how these systems are designed, moving away from trial-and-error tuning toward an approach that starts with a desired behavior and engineers backward. His framework targets applications such as micro-electro-mechanical systems, including ultrasensitive gas leak detectors capable of identifying hazardous compounds at parts-per-billion levels, as well as energy harvesters and aerospace structures.

In a system with bifurcations, a quantitative change produces a qualitative one: a change in the value of the input changes the type of outcome. Once a certain threshold is met, the system doesn’t do more of what it was doing; it instead does something different. For example, a somewhat flexible column loaded with heavier and heavier weights will compress more and more, but once a specific load is placed on it, it will move in a different way, bulging out to one side or buckling.

Today, researchers can characterize these kinds of systems using a lot of trial and error and analogies to previous systems. “Say I’m building a car, and I want it to have 400 horsepower,” Bajaj said. If he didn’t know how to hit that number, he might take any engine and keep tweaking it, tightening something here, disconnecting a part there, until it worked. And horsepower is an easy case, a smooth dial you can turn up or down. The challenge multiplies when the goal is a threshold behavior: getting a system to switch into a new kind of motion at exactly the right input, and not a moment before.

“Designing in bifurcation behavior can feel a bit like working in the dark,” Bajaj said. Even so, the field has made remarkable progress. Across nonlinear systems, libraries of relationships have accumulated for many decades as researchers test inputs and observe outputs via theory and experiment. They’ve found that systems with bifurcations of all kinds (a wing vibrating erratically at speed, a material buckling under pressure, a neuron firing in the brain) seem to be governed by similar principles. The equations aren’t identical, but when systems engineers compare notes, they find meaningful similarities behind the different variables and outputs.

“We play the same mathematical games, just on different fields,” Bajaj said. At a nonlinear dynamics conference, he might have a specific engineering question on his mind. “But then I could run into someone doing the same thing on a biological system and I think, ‘I can use their method to apply to my problem.’”

The award also supports an education plan that spans the length of the pipeline. Bajaj will carry the science of nonlinear behavior (the buckling and the sudden shifts that turn up everywhere from bridges to neurons) to K–12 students and the public through science center and library exhibits, and will fold the same design methods into undergraduate and graduate coursework. A layered mentorship model reaching students at different stages aims to broaden participation in STEM, giving newcomers both a way in and a reason to stay.

Bajaj will use his CAREER Award to develop a unified computational framework for designing nonlinear systems from a desired behavior, rather than discovering their behavior through trial and error. “I want to pick all my parameters, all the knobs I can turn, so that it does the things I want it to do and not necessarily the things that are undesirable.” The framework is intentionally general; he will demonstrate the approaches on small and large scales, from MEMS gas sensors at the micrometer scale to flutter in aircraft wings.

For more information: U.S. National Science Foundation

Team builds best-performing detection system for next-generation accelerators

Physicists at UC Santa Cruz and partner institutions in California and New Mexico have developed a new detection system designed to improve next-generation particle accelerators, enabling more precise studies of fundamental biological and chemical processes and supporting advances in materials science and energy research. The effort, led by the Advanced Accelerator Diagnostics Collaboration, which includes two University of California campuses and three U.S. national laboratories, addresses the growing need for high-rate beam diagnostics as accelerator performance increases from 120 pulses per second to as many as 1 million pulses per second, a jump that strains existing diagnostic systems.

“It really highlights the power of collaboration between universities and national laboratories,” said Bruce Schumm, the Long Family Professor of Experimental Physics. “If you took away Lawrence Berkeley Lab, if you took away Los Alamos, if you took away UC Davis, any of those, the whole thing would have fallen apart.”

The fruits of this years-long collaboration are nothing less than the best-performing high-bandwidth particle detection system built to date. The system combines artificial diamonds, custom microchips, and cutting-edge assembly techniques into a compact detector designed for measuring the properties of the beams shot by advanced accelerators like the Linac Coherent Light Source II at SLAC National Accelerator Laboratory in Menlo Park.

Need for speed

As next-generation particle accelerators continue to develop, they will have faster and faster bursts of charged particles that are close to each other in time. This means the researchers using them will need to create new, faster ways to measure these beams and control their properties.

“Nobody was building things that can measure, diagnose the beams and help control the accelerator, and also help the experimenters to unravel the data,” said Schumm.

At these high rates of beam repetition—eventually reaching beyond one billion times per second—existing detection systems fail. To overcome that barrier, the Advanced Accelerator Diagnostics Collaboration set out to redesign the entire detection chain from the sensor material itself, to the electronics used to read out the signal.

“It required developing a new approach to processing the signal, and also a new integrated circuit chip that we designed ourselves and then characterized,” said Schumm. “This is the first time we put it all together and put it into a beam.”

For more information: Physical Review Accelerators and Beams

Image: The detection system along with associated hardware for electronic conditioning and control. Photo by Carolyn Lagattuta.

UCLA researchers refine use of graphene oxide for stronger, more durable concrete

A UCLA-led study shows that adding graphene oxide, a carbon-based nanomaterial, to cement mixtures can produce stronger, more durable concrete, with performance driven more by even distribution than by quantity. Researchers found that ultrasonic treatment improves dispersion and delivers early strength gains at lower dosages, while controlled use of polymer surfactants helps enhance long-term strength by refining pore structures and reducing microcracks. The findings suggest practical ways to use less cement and lower carbon dioxide emissions tied to cement production.

Concrete is the world’s most widely used building material. Cement, the binding ingredient in concrete, accounts for about 8% of global carbon dioxide emissions. Enhancing the efficiency of cement use is therefore essential, as it would reduce the amount needed to build infrastructure — including buildings, roads and bridges — and help lower overall emissions. Graphene-enhanced concrete could last longer and require fewer repairs because stronger concrete cracks less easily and better resists water intrusion and corrosion, which in turn can increase its service life.

Researchers have known for more than a decade that adding graphene oxide to cementitious mixtures can increase concrete’s mechanical performance. However, earlier approaches produced inconsistent results, limiting suitability for commercial use.

To address this challenge, the UCLA team first dispersed graphene oxide powder in water and used ultrasound — the same type of technology found in inexpensive jewelry cleaners — to break up clumps and create a uniform mixture. They then added a moderate amount of polycarboxylate ether, or PCE, a common polymer additive that improves the mixture’s fluidity without adding extra water. This optimized sequence controls the exposed surface area of graphene oxide, thereby delivering strength gains at very low dosages, as little as 0.01% by mass of cement.

Graphene oxide is a nanomaterial derived from graphite and composed of carbon sheets one atom thick. In laboratory tests, adding graphene oxide to cementitious formulations using the optimized process improved the compressive strength by up to 25% after 28 days. The porosity was also significantly reduced by up to 50% as graphene oxide bridged microcracks, resulting in a denser structure.

“This study provides a comprehensive mechanistic framework to combine ultrasound processing, particle dispersants and small additions of graphene oxide to improve the performance of concrete,” said study co-corresponding author Gaurav Sant, a professor of civil and environmental engineering and the Pritzker Professor of Sustainability at the UCLA Samueli School of Engineering. The breakthrough builds on a long-term collaboration between Sant and co-corresponding author Richard Kaner, a distinguished professor of chemistry and biochemistry, through UCLA’s Institute for Carbon Management.

“Our group has spent nearly 20 years refining the synthesis and processing of graphene oxide, and more than a decade working with industry partners to scale production with consistently high quality,” said Maher El-Kady, a researcher working with Kaner. “It’s exciting to see that long-term effort culminate in a study with such clear societal relevance.”

The study’s first author is UCLA postdoctoral researcher Zhi Wan. The other co-corresponding authors are Torben Gädt, chair for the chemistry of construction materials at the Technical University of Munich, and Samanvaya Srivastava, a UCLA associate professor of chemical and biomolecular engineering. Additional UCLA authors include postdoctoral scholar Rui Xiao and chemical and biomolecular engineering graduate student Vihar Trada. Arizona State University researchers Sahil Surehali, a postdoctoral scientist, and Narayanan Neithalath, a professor of sustainable engineering, are also authors on the study.

At UCLA, Kaner holds the Dr. Myung Ki Hong Endowed Chair in Materials Innovation and has a joint appointment in materials science and engineering at UCLA Samueli. Sant is the director of the Institute for Carbon Management and holds a joint appointment in materials science and engineering. Both are faculty members with the California NanoSystems Institute.

For more information:  ACS Applied Engineering Materials

Image: Cement test samples (3-centimeter cubes) containing graphene oxide.

USC researchers develop 3D-printable MRI coils for low-cost, improved dynamic imaging

Diseases affecting moving organs such as the heart and lungs require dynamic imaging rather than static scans, yet limitations in current MRI technology often hinder early detection and diagnosis. Traditional MRI sensors are costly, rigid, and unable to conform closely to the body, reducing image quality and flexibility. To address this, researchers at the University of Southern California developed a low-cost, silver-ink MRI coil that can be 3D printed in under 10 minutes for patient-specific use. The coil costs about $30 in materials — significantly less than traditional models — and delivers up to four times higher image resolution, improving access to more reliable dynamic imaging.

USC researchers, Yasser Khan and Krishna Nayak teamed up to develop a new silver-ink based MRI coil that costs about $30 in consumable materials, compared with at least thousands of dollars for industry-standard coils, and delivers up to four times higher image resolution. The coils can also be 3D printed in real time in under 10 minutes, enabling patient-specific customization.

The study has removed key barriers in dynamic imaging and represents a major breakthrough in MRI technology, with broad applications in clinical settings such as pediatrics and cardiology.

The work was made possible by bringing together two researchers from USC Viterbi School of Engineering and USC Mark and Mary Stevens School of Computing with expertise in wearable sensors for precision health and MRI imaging: Khan, an assistant professor in the Ming Hsieh Department of Electrical and Computer Engineering and with joint appointments in the Alfred E. Mann Department of Biomedical Engineering, who leads Khan Lab; and Nayak, a professor of electrical and computer engineering, also with a joint appointment in biomedical engineering, who leads the Dynamic Imaging Science Center (DISC). The research was also spearheaded by Félix Muñoz, a student they co-advised, as well as Ye Tian, a research assistant professor in the Ming Hsieh Department of Electrical and Computer Engineering. The team also included Prof. Min-gu Kim, an assistant professor of medical engineering at Yonsei University in Korea.

John Wood, a close collaborator from the Keck School of Medicine of USC and the Children’s Hospital Los Angeles, emphasized that this is a game-changer, noting that MRI screening is a platform technology essential for detecting undiagnosed conditions in patients, including children and infants. He added that coil sensors play a critical role in diagnostic accuracy and clinical decision-making.

Expensive and Low-resolution MRI Scanners

Like cameras that detect light waves to form images, MRI scanners process and create images or videos using radiofrequency (RF) signals.

The visual data is made possible with MRI “coils,” which are specialized antennas placed close to the bohiiidy part being imaged to detect weak radiofrequency signals emitted by tissues, acting as the receiver for producing high-resolution images.

In the MRI world, the equivalent of camera resolution is called signal-to-noise ratio (SNR). To capture motion in MRI scans, specialized low-field MRI (0.55T) is used to enable dynamic, real-time imaging of motion-intensive processes by leveraging reduced susceptibility artifacts and faster data acquisition.

However, capturing video is particularly difficult at low magnetic field strengths (0.55T) because the signal is inherently weaker, which leads to lower SNR, and consequently lower resolution. Low SNR reduces image quality, making it more difficult for physicians to make accurate clinical assessments.

Today’s standard commercialized coils face many challenges, with low comformity being the biggest limitation. Current coils, typically made of copper, are rigid and follow a one-size-fits-all design. They cannot maintain the close contact required to recover enough signal for high-quality, video-rate imaging. The closer the sensors are to the signal source, the clearer the “picture,” and the closer a coil is to the anatomy, the better the resolution because proximity increases signal strength.

Existing MRI coil arrays are also expensive, priced between $10,000 and $50,000 each.

These high costs are driven by complex manufacturing processes, proprietary markups and rigid, specialized construction that can take significant time to produce. This cost and manufacturing complexity reinforce rigid designs as the commercial standard, making personalization difficult and continuing to limit imaging accuracy.

The limitations of current MRI technologies heavily affect babies and children, as Wood explained that existing coils are designed for adults and then scaled down for children, a process that often fails to accommodate the rapid anatomical changes in growing infants. This sizing mismatch makes MRI screening less accurate in pediatric patients. He also noted that “an infant’s heart can be as small as a walnut,” requiring a coil that is equally small and well-fitted to produce accurate results—something that current, non-customizable coil designs cannot adequately provide.

Silver-based MRI coils as solution: Flexible as human skin and engineered for higher SNR

In the study, Khan’s team aims to tackle the low SNR problem by designing coils that better fit the skin, allowing sensors to be closer to the body.

The lab first experimented with innovative materials that could maintain strong signal performance while being flexible enough to conform to the body like human skin—a longstanding challenge in MRIs for dynamic imaging.

A major limitation with flexible or printed conductors is that they typically have lower conductivity than solid copper, which introduces resistive losses and reduces signal-to-noise ratio (SNR). On the other hand, current industry-standard copper coils lack the flexibility needed to maintain close contact with the body. As high conductivity is key for strong SNR, most flexible materials have historically failed to deliver imaging performance comparable to copper.

Khan’s lab identified silver as an optimal material as it offers conductivity comparable to copper while enabling flexibility when printed onto soft, rubber-like substrates such as thermoplastic polyurethane (TPU). The researchers tested various silver inks and selected one formulation, FS0142, that achieved approximately 95% of the signal efficiency of a standard solid copper coil—the first time researchers are able to successfully address the conductivity challenge while maintaining flexibility for dynamic imaging at lower field.

The silver ink is combined with a specialized binder that makes it stretchable, allowing the printed coil to stretch between 5% and 10%, closely matching the natural stretchability of human skin. This enables the coils to wrap tightly around complex anatomical structures, such as the wrist, while maintaining consistent contact.

These new coils, which are as soft and stretchable as human skin, overcome the longstanding tradeoff between rigidity and conductivity. By ensuring a conformal interface where the coil remains in constant contact with the body, the design can effectively replace traditional copper coils while significantly improving imaging performance.

The $30 Breakthrough: 3D-Printed Coils That Are Customizable in Under 10 Minutes

The new coils are also drastically cheaper in both material cost and manufacturing, dropping the price of a standard coil from as much as $50,000 to about $120 per coil.

Muñoz explained that this is partly because the quantity of material needed per coil in his team’s study is extremely small, bringing the consumable cost to roughly $30 per element, despite silver being an expensive and precious metal.

The other key aspect contributing to the low cost is the lab’s automated workflow, which enables coils to be completely 3D printed. Unlike traditional coil manufacturing, which requires complex machinery, proprietary processes and intricate assembly steps that are costly, labor-intensive, the new coils introduced in the study can be produced in as little as eight minutes per element.

These coils are designed using standard Gerber files—the same format used to manufacture circuit boards—allowing for a fully digital workflow. By using automated tools such as the Voltera NOVA printer, a direct-ink-write system, the need for manual routing or complex housing assembly is eliminated, enabling rapid digital fabrication.

This innovation not only reduces cost but also expands the potential for MRI to become more accessible, instead of a limited, high-cost resource. The simple, low-cost, real-time production of these coils allows for on-demand manufacturing tailored to specific patients or body parts, further addressing the longstanding challenge in customization. This makes it possible to create coils of varying sizes, including those small enough for infants.

Because the coils are inexpensive and can be analyzed using low-cost, portable tools, the technology could expand access to high-quality MRI in rural or resource-limited settings worldwide.

At USC, New Coils Meet the World’s Only Low-Field High-Performance MRI System

This work was made possible through a unique collaboration at the University of Southern California, where the newly developed coils could be directly tested on a rare high-performance low-field MRI system—creating an environment that enables proprietary research, innovation and cross-disciplinary collaboration.

A key advantage is the close partnership between Yasser Khan’s lab, which developed the coils, and the Dynamic Imaging Science Center. The center houses a highly specialized MRI scanner: a 0.55 T low-field prototype, a modified 1.5 T Siemens MAGNETOM Aera system, that is now the only one of its kind still operating in the world.

The scanner at DISC offers several technical advantages that make it an ideal match for the new flexible coil technology. Its advanced gradient system enables extremely fast scans, which are essential for capturing high-quality, video-rate dynamic imaging. At the same time, like most low-field MRI systems, the scanner at DISC suffers from lower signal. The flexible coils developed in this study address that limitation by improving signal capture and image quality.

What’s Next: Clinical Use and Patient Testing

The study’s MRI coils have generated strong interest among physicians. Khan said the team’s goal is to move the coils from the lab into clinical settings, with patient testing as a key next step.

Nayak identified pediatric lung imaging as a likely first clinical application to be tested, with John Wood expressing strong interest in eventually adopting the technology for patient care.

“It starts with a signal,” Wood emphasized, noting that regardless of the medical condition, the diagnostic process begins with signal and image quality. He said the study introduces significantly improved signal strength, which could enhance MRI as a platform technology across many diseases and help physicians make more accurate clinical judgments.

Wood emphasized that the technology could be especially impactful for the smallest and most fragile patients, including premature infants. An infant’s heart is extremely small and beats rapidly, making it traditionally difficult to image. Improving signal by bringing the “lens”—the coil—closer to the body allows for clearer visualization of these tiny, fast-moving structures. Screening is a critical first step in identifying conditions in infants, who are more vulnerable to heart and lung diseases or structural abnormalities that require accurate imaging.

Wood also envisions new diagnostic pathways for common infant conditions, including monitoring lung development in bronchopulmonary dysplasia, evaluating swallowing function to prevent aspiration, and studying gastrointestinal malformations.

Muñoz also highlighted applications in wrist injuries, which require clear dynamic imaging of moving joints to identify conditions. In testing, the team’s wrist coil arrays achieved four times higher contrast and five times greater sharpness than commercial coils, allowing clinicians to resolve fine structures such as carpal ligaments that were previously difficult to see.

While the coils were developed to address challenges in dynamic imaging, Wood sees broader applications in standard, still-image MRI scans across a range of clinical settings.

For more information: Nature Communications
